Toyota Traigo 80 Akülü Forklift 2,0 – 5,0 t

Toyota Traigo 80: 2.0 – 5.0 t four-wheel electric forklifts with 80 V AC drive (8FBMKT / 8FBMT). IC-level performance with zero emissions; lift heights up to 6.5 m and 20 km/h travel speed.

Lifting capacity: 5 t
Lift height: 6.5 m
Machine weight: 7.72 t

Request a price

Technical brochure (PDF) 0532 326 50 75

Manufactured to CE and EN 280 standards
Mobile service and periodic maintenance
Certified operator training on delivery

Key features

Toyota Traigo 80 Akülü Forklift 2,0 – 5,0 t — why choose it?

2.0 / 2.5 / 3.0 / 3.5 / 4.0 / 4.5 / 5.0 t capacity
80 V AC power system; 20 kW (25.2 kW) drive and 25.5 kW lift motor
Lift heights up to 6.5 m with V, FV, FW, FSV, FSW masts
20 km/h travel speed; gradeability up to 29%
Toyota SAS, ORS seat, wet disc brakes
Seat-mounted hydraulic mini-levers, digital multifunction display
Memory tilt steering column, emergency stop in armrest

Toyota · Forklifts and Warehouse Equipment

Specifications

Toyota Traigo 80 Akülü Forklift 2,0 – 5,0 t

Values are based on manufacturer data; may vary by options and configuration.

Download brochure (PDF)

Kaldırma kapasitesi: 2 000 – 4 990 kg
Yük merkezi: 500 mm (5,0 t: 600 mm)
Standart asansör (h3): 3 300 mm
Maks. kaldırma yüksekliği: 6 540 mm (FSW)
Sürüş hızı (yüklü/yüksüz): 19 / 20 km/sa (4,0 – 5,0 t: 18 km/sa)
Tırmanma kabiliyeti (maks.): %29
Akü: 80 V / 420 – 840 Ah
Sürüş motoru: 20 kW (4,0 – 5,0 t: 25,2 kW), AC
Kaldırma motoru: 25,5 kW
Genişlik: 1 195 – 1 440 mm
Dönüş yarıçapı: 1 872 – 2 686 mm
Servis ağırlığı: 4 198 – 7 721 kg
Modeller: 8FBMKT20 · 8FBMKT25 · 8FBMT25 · 8FBMKT30 · 8FBMT30 · 8FBMT35 · 8FBMT40 · 8FBMT45 · 8FBMT50

FAQ

Toyota Traigo 80 Akülü Forklift 2,0 – 5,0 t
questions

Traigo 80 dizel forkliftin yerini alabilir mi?

Evet; 80 V AC sistemle 20 km/sa hız, %29 tırmanma ve 5 tona kadar kapasite sunar. Kapalı alan veya düşük emisyon şartı olan sahalarda içten yanmalı forkliftlerin yerine kullanılır.
